22.5° Double Socket Bends

22.5° Double Socket Bends
双承22.5度弯头
DN
L
Mass without glands (kg)
Mass with glands (kg)
Mass completely (kg)
standard
60
35
4.50
6.02
7.58
　
80
40
6.10
8.06
10.40
　
100
40
9.00
12.20
14.54
　
125
50
12.00
15.80
18.14
　
150
55
15.00
19.40
22.52
　
200
65
21.50
27.90
31.80
　
250
75
28.80
37.60
42.28
　
300
85
36.00
46.40
51.86
　
350
95
49.20
62.20
68.44
　
400
110
59.20
74.80
81.04
　
450
120
77.00
98.40
105.12
　
500
130
96.20
126.60
135.00
　
600
150
138.20
178.20
188.40
　
700
175
223.00
　
　
　
800
195
281.00
　
　
　
900
220
364.00
　
　
　
1000
240
463.00
　
　
　
1100
260
560.00
　
　
　
1200
285
671.00
　
　
　
1400
260
882.00
　
　
　
1500
270
1011.00
　
　
　
1600
280
1167.00
　
　
　
1800
300
1533.00
　
　
　
2000
330
1965.00
　
　
　
2200
355
2441.00
　
　
　
2400
380
2986.00
　
　
　
2600
400
3778.00
　
　
　
